NON RETURN VALVE STAINLESS STEEL

CV300 SSG CHECK VALVE, FOR PURE GASES
seat material stainless steel/ceramics, 300 bar working pressure, body stainless steel

Used in pipelines, the CV300 SSG prevents an undesirable flow in the opposite direction to the main flow direction.

Mounted in the high-pressure area of manifolds of pure gas supply systems, the CV300 SSG protects the compressed gas cylinders against transfer in the event of incorrect operation. The CV300 SSG can be used in supply systems for inert, flammable, oxidising and corrosive gases up to a gas quality of 6.0.

SPECIAL FEATURES

The special seat seal and the use of selected gas-wetted parts allow the use with oxygen up to 300 bar working pressure. The Oxygen ignition test for non-metallic seat sealed check valves which is required during the development phase can be omitted with the CV300 SSG due to targeted material selection.

  • Compact design
  • Designed and approved in accordance with relevant sections of EN ISO 10297:2015
  • Specially cleaned

TECHNICAL DATA

Working temperature: -20°C to +60°C
Inlet connection: NPT 1/4" female
Outlet connection: NPT 1/4" male
Max. working pressure: 300 bar
Length: 54 mm
Weight: 0,1 kg
Material:
   Valve body: Stainless Steel 316L
   Filter: AISI 316L
   Valve seat: Ceramic (Si3N4)
   Spring: Stainless Steel 316L
