MEDIVITAL®

Whole medical range is available on

Pressure regulator integrated with cylinder valve for use with medical gases.

EXTENDED SERVICE LIFE

Service life time ensured by extended endurance and cycle testing for future market requirements
Slow opening shut off valve with new Patented design
Latest technology highest shock resistant gauge
Flow selector designed for optimal gas flow and patient safety
Guard design provides maximum protection for the valve

USER FRIENDLY

Suitable for use in Homecare, Emergency and Hospital applications
Easy read Flow Selector and Gauge
Shut off valve with clear open /closed status colour coded marking
Ergonomic guard design allows easy handling of the cylinder package by all users
Compact and lightweight design less than 2,56 lb
Easy clean guard material

HIGHEST SAFETY

Testing in accordance with the following standards, EN ISO 10524-3, ASTM G175 Pill test, EN ISO 10297
CE marked CE 2460 in accordance with the MDR (EU) 2017/745 and TPED 2010/35 EU
Phthalate and Halogenated polymer free components
MRI compatible up to Tesla 3
For use with medical Oxygen, Air, O₂/N₂O, He/O₂ up to 3000 psi working pressure

735100001549 MediVital leaflet EN US

TECHNICAL DATA

Gas:	O₂, Air, O₂/N₂O, He/O₂
Inlet pressure:	Up to 3000 psi (207 bar)
Outlet pressure:	52 psi to 80 psi - acc. to EN ISO 10524-3 (or per customer specification)
RPV closing:	> 43,5 psi
PRV opening and re-closing:	> 80 psi
Flow ranges:	0-6, 0-15 and 0-25 lpm
Materials:
Metallic parts (gas wetted):	brass
Elastomers:	EPDM, silicon, PUR
Plastics:	PA66, PEEK
Springs (gas wetted):	CuBe₂, CuSn₆
Dimensions:
Height:	6,02 inch
Width:	4,41 inch
Depth:	4,65 inch
Weight:*	2,56 lb
Inlet stem:	Tapered or parallel threads (17E, 25E, M18 x 1,5 per customer specification)
Filling port:	ISO 5145 or per customer specification
Regulatory status:	Complies with MDR (EU) 2017/745 Complies with TPED 2010/35/EU Complies with EN ISO 10524-3 Complies with EN ISO 10297 Complies with EN 1789 Complies with ASTM G175 Production in accordance with EN ISO 9001 and EN ISO 13485
Classification:	Class IIb

^{* Standard Combivalve (flow control unit 0 - 15 l/min, flow outlet, DIN quick coupling pressure outlet) with the guard.
All technical data are given for information only and are subject to modifications by the manufacturer.}

RELATED PRODUCTS

Art.nr.	Description
0727421	Bed hanger (10 pcs)
0727427	Bed hanger with black plastic sleeves - 10 pcs
0727418	Humidifier holder 9/16 (10 pcs)
14112760	Connecting hose for humidifier holder 40 cm - 1 pc
0727422	Valving tool (1 pce)
on request	Filling adaptor
